Carlo Gavazzi Type PA2 Contact Block 2 NO contacts (DPST) Snap action
PA2200/1
Delivery
Payment options
Our advantages
- — 12 months warranty
- — SMS notification
- — Return and exchange
- — Different payment methods
- — Best price
Column filling
| Sort by Price | Sort by Availability | Sort by CODE | Sort by Options | Sort by Contacts |
|---|---|---|---|---|
Contact us for a price
|
In stock
|
PA2200/1
|
Options:
|
Contacts:
|
Features
- -13°F to 158°F (-25°C to 70°C) operating temperature
- -22°F to 176°F (-30°C to 80°C) storage temperature
- Double switch
- 10A switching capacity
- Up to 500VAC
- Modular mounting of up to 3 elements
- Screw terminals
- Industrial applications
The Carlo Gavazzi Type PA2 Contact Block supports double pole single throw (DPST) configurations available with 2 NO contacts, 2 NC contacts, or 1NC + 1NO contacts. Hard silver is the standard contact material, copper is used for contact parts, and the switch housing is polycarbonate. The contact block functions on a minimum switching power of 100mA (current) and 24V (voltage).
