Adash A4500 VA5 Pro Vibration Analyzer VA5 Base: A4500 Vibration Analyzer, charger, leather cover, carrying strap, Pro Transport Case
- — 12 months warranty
- — SMS notification
- — Return and exchange
- — Different payment methods
- — Best price
| Sort by Price | Sort by Availability | Sort by CODE | Sort by Solo + Kit Options |
|---|---|---|---|
Contact us for a price
|
In stock
|
A4500 INST
|
Solo + Kit Options:
|
|
Contact us for a price
|
In stock
|
A4500 BPK
|
Solo + Kit Options:
|
|
Contact us for a price
|
In stock
|
A4500 PROK
|
Solo + Kit Options:
|
Features
- Adash A4500 VA5 Pro Four Channel Vibration Analyzer:
- Sampling mode: fully simultaneous for 4 channels
- 4 AC inputs for vibration measurement
- 4 DC inputs for process values measurement
- Tacho input (speed/trigger)
- Input range:
- AC +/- 12V peak-peak
- DC +/- 24V
- AD conversion: 24 bit, 64 bit internal signal processing (no auto-gain)
- Frequency ranges (-3dB):
- maximum range: 0.35 Hz - 90 kHz (1 Ch, 194 kHz sampling)
- maximum range: 0.35 Hz - 25 kHz (4 Ch, 64 kHz sampling)
- minimum range: 0.35 Hz - 25 Hz (4 Ch, 64 Hz sampling)
- FFT Resolution: 3,276,800 lines
- Memory/Route: 64GB max. 16GB for one route
- USB 3.0 (2.0 compatible)
- Operating temperature range: -10 to 50˚C
- Lithium Ion battery: 8 hours of operation, AC 230V
- Touch screen display
- Built in camera (thermal imaging camera sold separately)
The Adash A4500 VA5 Pro Four Channel Vibration Analyzer is a powerful, portable vibration analyzer with thermal imaging and ultrasound capabilities. The A4500 VA5 Pro is compatible with triaxial sensors, and can simultaneously measure up to four vibration signals, four process values and speed. This program runs with FFT with a resolution maximum over 3.25 million lines. Featuring a 9 inch touch screen display and 64GB of storage, the A4500 VA5 Pro has plenty of memory for extensive data collection and analysis, with a user-friendly interface that makes on site review a breeze.
A library of modules is pre-installed on the A4500 VA5 Pro to provide the user with access to an expert level analysis program, including but not limited to: route measurements, dynamic balancing, raw signal recording, machine noise logging, automatic fault detection, bump tests, ultrasound, and thermal imaging analysis(see Accessories tab for thermal camera attachment and ultrasound microphone). With extensive data collection options, a modular design and an 8 hour battery life, the A4500 VA5 Pro is a premier choice for vibration analysis applications. Experience a taste of the A4500 VA5 Pro's capabilities before purchase with the free download of Adash's Software Environment Emulator(see Documents tab).
The Adash A4500 VA5 Pro Vibration Analyzer Kit options have been configured to give the user access to all essential hardware and software basics for a cutting edge vibration analysis program. Purchase of a VA5 Base Kit provides the user with all the logistical gear for safe transport of the analyzer and its accessories, including a leather cover, shoulder strap and hard-shell carrying case. For more advanced analysis capabilities, the VA5 Pro Kit provides a licensed seat to the professional version of Adash's Digital Diagnostics Software (DDS).
Experience a taste of the A4500 VA5 Pro's capabilities before purchase with the free download of Adash's Software Environment Emulator(see Documents tab).
